SANNCE 8MP Home Surveillance Kit 8CH H.265+ Video NVR Recorder 4×Security Protection Cameras Two-way voice Remote Access System
Key features:
★ 8MP high definition live viewing & recording
★ 8MP high definition playback channel
★ Support human detection
★ Vehicle shape detection, face capture(requires IPC support)
★ Up to 10 channels,8 built-in PoE inputs
★ Advanced H.265+ Video Compression
★ Two-way voice intercom, built-in microphone and speaker
★ Includes 4PCS 8 Megapixel Resolution POE outdoor IPC
★ Support DC12V and PoE dual power supply
★ Up to 100ft night vision with SmartIR
★ IP66 Dust and Waterproof Rating
★ Support onvif protocol
NVR | ||
Video & Audio | Video Compression | H.265+ |
IP Video Input | 8CH POE+2CH | |
Video Output | HDMI Up to 4K | |
Audio Output | Support | |
Max Recording Resolution | Up to 8M(3860x2160) | |
Max Playback Resolution | Up to 8M(3860x2160) | |
Max Playback Channel | 4CH | |
Max Playback Capacity | 4CH 3MP/2CH 5MP/1CH 8MP | |
Onvif | Support | |
Hard Drive | HDD | 1 SATA interface |
HDD Capacity | Up to 12TB capacity | |
| Network interface | RJ45x1(10/100/1000M) |
POE | 8 Ports(IEEE802.3at/af) | |
USB | USB2.0x2 | |
General | Housing | Metal for main part |
Operating Power | DC48V | |
Power Consumption | 10W(without HDD) | |
POE: Max 30W for single port | ||
Working Temperature | 32 °F – 131 °F /0 °C – 55 °C | |
Dimensions(W x H x D) | 260x245x47mm | |
Weight (without hard disk) | 820g(without HDD) | |
IP Camera | ||
Camera | Video Resolution | 8MP(3840×2160) |
Image sensor | 1/2.7" Progressive Scan CMOS | |
Video compression | H.265+ | |
Audio Compression | G.711A | |
Lens | 2.8mm | |
Angle of View | 105° | |
Number of Infra-Red LEDs | 36 | |
Night Vision Distance | Up to 100ft/30m | |
Wide Dynamic Range | Digital WDR | |
IR Cut Filter | YES | |
Ethernet | RJ45x1(10M/100M) | |
Onvif | Support | |
General | Housing | Metal |
Operating Power | DC12V;PoE (802.3af) | |
Operating Temperature | -4 °F – 140 °F /-20 °C – 60 °C | |
Indoor/Outdoor | Indoor/Outdoor | |
Weatherproof Rating | IP66 | |
Dimension (L x W x H) | 170 x 65 x 65mm | |
Weight | 350g | |
Packaging Contents | ||
NVR | 1 | |
Camera | 4 | |
Ethernet Cable | 60ft/18m x2;100ft/30m x2 | |
USB Mouse | 1 | |
Power Adapter | 1 | |
Mounting Screws Bag | 4 | |
Quick Start Guide | 1 | |
Package Dimension (L x W x H) | 390×270×160mm | |
Package Weight | 4.48Kg(without HDD) | |
