Original Dahua 8MP 4K IP Camera IPC-HDW3849H-AS-PV SD WizSense Tioc Color Night Vision Security Cam Mic Speaker Audio

> 1. About camera:

This model is 100% original Dahua IP camera, it support firmware updating!

> 2. About Shipment:

If you can order ≥ 10pcs cameras , we will try to send items via fast shipping for free.

We will choose the best shipping method for your order according to our experience as different countries has different shipping rules . Besides , wish you kindly understand that we could not remove the shipping cost for you if your shipping cost is too high.

> 3. About Service:

Please contact our customer service if any doubt , We can support Skype/WhatsApp/WeChat , please contact our customer service to get the ID because we can't leave any contact information here as the rule of aliexpress.

> 8 MP 1/2.8" CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED; the max. IR illumination distance is 30 m and warm light distance is 30 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; buit-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/PoE power supply.

> IP67 protection.

> Sound and light alarm (red and blue lights).

> SMD 3.0.

> One press arming/disarming through alarm input.

Model: IPC-HDW3849H-AS-PV
1.Camera :
Image Sensor : 1/2.8'8Megapixel progressive CMOS
Max. Resolution : 3840(H) × 2160 (V)
ROM : 128 MB
RAM : 512 MB
Scanning System : Progressive
Electronic Shutter Speed : Auto/Manual 1/3 s–1/100,000 s
Min. Illumination : 0.007 Lux @ F1.4
S/N Ratio : > 56 dB
Illumination Distance : 30 m (98.4 ft)
Illuminator On/Off Control : Auto/Manual
Illuminator Number : 1 (Warm light)
Pan/Tilt/Rotation Range : Pan: 0°–360°;Tilt: 0°–78°;Rotation: 0°–360°

2.Lens :
Lens Type : Fixed-focal
Mount Type : M12
Focal Length : 2.8 mm; 3.6 mm
Max. Aperture : F1.4
Field of View : 2.8 mm: Horizontal 107° × Vertical 56° × Diagonal 127°;3.6 mm: Horizontal 89° × Vertical 46° × Diagonal 102°
Iris Type : Fixed
Close Focus Distance : 2.8 mm: 1.5 m (4.9 ft);3.6 mm: 2.2m (7.2 ft)

3.Professional, intelligent :
IVS (Perimeter Protection) : Tripwire; intrusion (support the classification and accurate detection of vehicle and human)
Intelligent Search : Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.

4.Video :
Video Compression : H.265; H.264; H.264H; H.264B; MJPEG(only supported by the sub stream)
Smart Codec : Smart H.265+/Smart H.264+
Video Frame Rate : Main stream:3840 × 2160 @(1–20 fps by default);3840 × 2160 @(1–25/30 fps with AI function disabled);sub stream: 704 × 576 @ (1–25 fps)/704 × 480 @ (1–30 fps);third stream:1280 × 1080 @ (1–25/30 fps)
Stream Capability : 3 streams
Resolution : 8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1(704 × 576/704 × 480);VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control : CBR/VBR
Video Bit Rate : H.264: 32 kbps–8192 kbps;H.265: 12 kbps–8192 kbps
Day/Night : Color/B/W
BLC : Yes
HLC : Yes
WDR : 120 dB
Scene Self-adaptation (SSA) : Yes
White Balance : Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control : Auto/Manual
Noise Reduction : 3D NR
Motion Detection : OFF/ON (4 areas)
Region of Interest (RoI) : Yes (4 areas)
Smart Illumination : Yes
Image Rotation : 0°/90°/180°/270° (Support with 1920 × 1080 resolution and lower)
Mirror : Yes
Privacy Masking : 4 areas

5.Audio :
Built-in MIC : Yes
Audio Compression : PCM, G.711a, G.711Mu, G726

6.Alarm :
Alarm Event : No SD card; SD card full; SD card error; service life warning (supported by DH card); network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; external alarm; SMD; safety exception; light alarm; sound alarm (11 built-in sounds and custom voices importing)importing)

7.Network :
Network : RJ-45 (10/100 Base-T)
SDK and API : Yes
Protocol : IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP
Cyber Security : Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Interoperability : ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P
User/Host : 20 (Total bandwidth: 80 M)
Storage : FTP; SFTP; Micro SD card (support max. 256 G); NAS
Browser : IE: IE8 and later/Chrome/Safari: Safari 12 and later/Firefox
Management Software : Smart PSS; DSS; DMSS
Mobile Phone : IOS; Android

8.Certification :
Certification : CE-LVD: EN62368-1;CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;FCC: 47 CFR FCC Part 15, Subpart B

9.Port :
Audio Input : 1 channel (RCA port)
Audio Output : 1 channel (RCA port)
Alarm Input : 1 channel in: 5mA 3V–5V DC
Alarm Output : 1 channel out: 300mA 12V DC

10.Power :
Power Supply : 12V DC/PoE (802.3af)
Power Consumption : Basic power consumption: 3.1W (DC12V); 3.5W (POE)Max. power consumption (WDR + H.265 + red and blue lights flashing alternately + warm light + sound alarm): 7.8W (DC12V); 8.2W (POE)

11.Environment :
Operating Conditions : –40°C to +60°C (–40°F to +140°F)/Less than 95% RH
Storage Conditions : –40°C to +60°C (–40°F to +140°F)
Protection Grade : IP67

12.Structure :
Casing : Metal
Dimensions : Φ122.0 mm × 110.9 mm (4.8" × 4.4")
Net Weight : 754 g (1.7 lb)
Gross Weight : 915 g (2.0 lb)

Packing-List :
1. 1x 8 mp IP Camera IPC-HDW3849H-AS-PV S4 Version
2. 1x User manual .
3. 1x Waterproof plug .
4. Installation tool .
5. 1x screws bag.
6. 1x Drill Template .
