Dahua NVR2216-16P-I2 16CH NVR 16CH 1U 16POE 2HDDs WizSense 12MP Resolution Face Recognition WizSense 4K Network Video Recorder
Dahua NVR2216-16P-I2 16CH NVR 16CH 1U 16POE 2HDDs WizSense 12MP Resolution Face Recognition WizSense 4K Network Video Recorder
Features
NVR2208-8P-I2/NVR2216-16P-I2
8/16 Channel 1U 8/16PoE 2HDDs WizSense Network Video Recorder
> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format
> Max. decoding capability: 6 × 1080p@30 fps. Supports adaptive decoding
> 1-channel face detection and recognition (AI by NVR); 1-channel perimeter protection (AI by NVR); up to 10 face databases and 5,000 face images; 4-channel SMD Plus (AI by NVR);
> AI by camera: Face detection and recognition, perimeter protection, and SMD Plus
> Connected to the third-party network cameras
> Security baseline 2.1
1.System
Main Processor:Industrial-grade embedded processor
Operating System:Embedded Linux
Operation Interface:Web; local GUI
2.AI
AI by Camera:Face detection; face recognition; perimeter protection; SMD Plus
AI by Device:Face detection; face recognition; perimeter protection; SMD Plus
Perimeter Protection
Perimeter Performance AI by Device(Number of Channels):1
Perimeter Performance of AI by Camera (Number of Channels):4
3.Face Detection
Face Attributes:6 attibutes: Gender; age group (6); glasses; expressions (8); mouth mask; beard
Face Detection Performance of AI by Device (1080P) (Number of Channels):1 (up to 12 face images/second)
Face Detection Performance of AI by Camera (Number of Channels):5
4.Face Recognition
Face Database Capacity:Up to 10 face databases with 5,000 images
Face Recognition Performance of AI by Device (1080P) (Number of Channels):1 (up to 4 face images/second)
Face Recognition Performance of AI by Camera (Number of Channels):5
5.SMD Plus
SMD Plus by Device:4
SMD Plus by Camera:6-channel SMD Plus (AI by camera): Detects tripwire and intrustion of human or vehicle; filters false alarms caused by leaves, raindrops and change of brightness away
6.Video
Access Channel:8/16 channels
Network Bandwidth
AI off: Access: 144 Mbps; Storage: 144 Mbps; Forward: 72 Mbps
AI on: Access: 72 Mbps; Storage: 72 Mbps; Forward: 36 Mbps
Resolution:12MP; 8MP; 5MP; 4MP; 3MP; 2MP; 720p; D1
Decoding Capability
AI disabled: 1-channel 12MP@30 fps; 1-channel 8MP@30 fps; 2-channel 5MP@30 fps; 3-channel 4MP@30 fps; 6-channel 1080p@30 fps
AI enabled: 1-channel 8MP@30 fps; 1-channel 5MP@30 fps; 2-channel 4MP@30 fps; 4-channel 1080p@30 fps
Video Output:1 × VGA, 1 × HDMI (simultaneous)
Multi-screen Display:1, 4, 8, 9 views
Third Party Camera Access:Onvif
7.Compression
Video:Smart H.265+; H.265; Smart H.264+; H.264; MJPEG
Audio:PCM; G711A; G711U; G726
8.Network
Network Protocol:HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); P2P;Auto Registration
Mobile Phone Access:Android; iOS
Interoperability:ONVIF (profile T; profile S; profile G); CGI; SDK
Browser:Chrome; IE9 or later; Firefox
9.Record Playback
Multi-channel Playback:Up to 8 channels
Record Mode:Manual record; alarm recordings; motion detection recordings; scheduled recordings
Storage:Local HDD and network
Backup:USB device
10.Playback Function
1. Play; pause; stop; fast forward; fast backward; rewind; play by frame
2. Full screen; backup (vide clip/file); partially zom in; audio on/off
11.Alarm
General Alarm:Motion detection; privacy masking; video loss; PIR alarm; IPC alarm
Anomaly Alarm:Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; cyber security exception
Intelligent Alarm:Face detection; face recognition; perimeter protection (intrusion and tripwire); IVS; SMD Plus
Alarm Linkage:Recording; snapshot; buzzer; log; preset; email; tour
12.External Port
HDD:2 SATA ports, up to 10 TB. The maximum HDD capacity varies with environment temperature
USB:1 × front USB2.0; 1 × back USB2.0
HDMI:1 (max. resolution: 4K)
VGA:1
Network:1 × RJ-45, 10/100/1000 Mbps
PoE:8 × PoE ports, 10/100 Mbps
RCA Input:1
RCA Output:1
13.General Parameter
Power Supply:54 V DC, 2.22 A
Power Consumption:Total output of NVR is ≤ 10W (without HDD)Total output power of PoE is 80W, the maximum output power of a single port is 25.5W
Net Weight:1.72 kg (3.79 lb)
Gross weight:3.07 kg (6.77 lb)
Product Dimensions:375 mm × 284.3 mm × 53 mm (14.76" × 11.19" × 2.09") (W × L × H)
Package Dimensions:141 mm × 433 mm × 366 mm (5.55" × 17.05" × 14.41") (W × L × H)
Operating Temperature:–10 °C to +55 °C (+14 °F to +131 °F)
Storage Temperature:0 °C to 40 °C (32 °F to 104 °F)
Operating Humidity:10%–93%
Storage Humidity:30%–85%
Operating Altitude:3,000 m (9,842.52 ft)
Installation:Desktop
Certifications:FCC:47 CFR FCC Part15,SubpartB,Class A
CE-EMC:EN 55032:2015,Class A;EN IEC 61000-3-2:2019;EN 61000-3-3:2013+A1:2019;EN 55024:2010+A1:2015;EN 55035:2017;EN 50130-4:2011+A1:2014
CE-LVD:EN 62368-1:2014+A11:2017
