ANNKE 5MP POE Video Surveillance Kit 8CH 6MP H.265+ NVR Security Protection Camera Weatherproof Audio POE Camera CCTV System
[True 3K Super HD at 20 fps]
With the advanced OmniVision sensor, 120 dB true WDR & 3D DNR, this IP camera brings industry-leading 3K Super HD at smooth 20 fps (2592 X 1944 pixels).
Up to 116° diagonal FoV for 2.8 MM /4.4MM lens, to cover wide-range areas like foyers, front/back doors or yards, parking lots, warehouses, etc.
[EXIR 2.0 Night Vision with External Lighting]
ANNKE-designed color night vision tech enables the camera to produce colorful videos over 0.028 lux illumination with the external light sources around the camera.
Equipped with the exceptional EXIR tech & smart IR, the camera delivers up to 100 ft long-range black & white night vision in 0 lux illumination conditions, which are too dark to render color images.
[Noise-Cancelling Audio]
The built-in noise-cancelling microphone can filter the environment noise automatically, and pick up the voice from up to 20 ft away.
Listen-in Audio: Audio recording enhances the security coverage and the ability to interpret events. Record videos with vivid sound instead of silent footages.
Mute Function: Audio record might be regulated based on your location. If the audio surveillance is not allowed or you don't want audio record, simply mute it.
[IP67 Weatherproof – Extreme Weather Capabilities]
IP67 rated, the camera is fully weatherproof & can be immersed in 1 m of water for 30 mins. It continues to operate in extreme temperatures as low as -22 °F (-30 °C). Torrential downpours, heavy winds, freezing snow storms, the camera braves them all.
NVR:
Video & Audio | Video Compression | H.265+/H.265/ H.264+/H.264 |
IP Video Input | 8CH POE | |
Video Output | HDMI & VGA Up to 1080P | |
Incoming bandwidth | 60M | |
Max Recording Resolution | Up to 6MP | |
Max Playback Resolution | Up to 6MP | |
Max Playback Channel | 8CH | |
Max Playback Capacity | 4-ch@1080P, 1-ch@6MP@25fps | |
Onvif Protocols | Support | |
Hard Drive | HDD | 1 SATA interface |
HDD Capacity | Up to 6TB capacity | |
| Network interface | RJ45x1(10/100M) |
POE | 8 Ports(IEEE802.3af/at) | |
USB | 2x USB 2.0 | |
General | Operating Power | DC48V |
Power Consumption | ≤10W(without HDD and POE) | |
POE: Max 25.5W for single port | ||
Working Temperature | 14 °F ~ 131 °F /-10 °C ~+55 °C | |
Dimensions(W x H x D) | 10.4" × 8.9" × 1.9" / 265 × 225 × 48mm | |
Weight (without hard disk) | 2.2lb / 1KG |
Camera:
Camera | Image Sensor | 1/3" Progressive Scan CMOS |
Max resolution | 3K(3072*1728), 16: 9 picture ratio is more suitable for the most popular display | |
Main Stream | 50 Hz: 20 fps (3072*1728), 25 fps ( 1920 X 1080, 1280 X 720) | |
Substream | 50 Hz: 25 fps (1280 X 720,640 X 480, 640 X 360) | |
Video Compression | Main stream: H.265+/H.265/H.264+/H.264 | |
Video Bitrate | 32 Kbps - 6 Mbps | |
Audio Compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC | |
Audio Input | Built-in Microphone, record with audio | |
Lens | 4 mm | |
Min. Illumination | Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR | |
Angle of View | Horizontal FOV 76°, vertical FOV 41°, diagonal FOV 90° | |
Number of Infrared LEDs | 2 pcs | |
Night Vision Distance | Up to 100 ft/30 m | |
Motion detection 2.0 | Supoort, include Human & Vehicle detection | |
Image Enhancement | BLC, HLC, 3D DNR | |
Wide Dynamic Range | 120 dB WDR | |
Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, Bonjour, FTP, SMTP | |
ONVIF | Support | |
Region of Interest (ROI) | 1 fixed region for main stream | |
Privacy Mask | 4 programmable polygon privacy masks | |
General Function | Mirror,rotate,password protection,video tampering alarm, remote access | |
Ethernet | 1 RJ45 10 M/100 M self-adaptive Ethernet port | |
General | Housing | Metal & Plastic |
Color | White | |
Storage | Built-in microSD/SDHC/SDXC Slot, up to 256 GB | |
Hardware Reset | Yes | |
Operating Power | DC 12 V± 25%, max. 5 W; PoE (802.3af), max. 6.5 W | |
Operating Temperature | -22 °F – 140 °F/-30 °C – 60 °C | |
Indoor/Outdoor Use | Indoor/Outdoor | |
Interface Protection | IP67, TVS 2000 V Lightning Protection, Surge Protection and Voltage Transient Protection | |
Dimension (L X W X H) | Ø 110 × 100.8 mm (Ø 4.3" × 4.0") | |
Weight | 0.6 lb./270 g |
