ANNKE 5MP POE Video Security Camera System Smart Home Video Surveillance H.265+ Night Vision IR Network Two Way Audio Cameras
Follow the store for more discounts! !
Key features:
NVR:
· 6MP high definition Real-time live viewing, recording&playback
· Up to 8 channel IP camera connectable with built-in PoE inputs
· Advanced H.265+ compression effectively reduces the storage space by up to 75%
· Smart playback to improve the playback efficiency
· Supports iPhone, iPad, Android mobile remote monitoring
· Annke vision for easy remote monitoring
Camera:
★ 3K IR Network Bullet Camera with audio input
★ 4mm lens brings everything back to life
★ Efficient H.265+ compression technology
★ Motion detection 2.0 with human & Vehicle Detection
★ Up to 100ft night vision with EXIR 2.0
★ Clear day and night vision with 3D DNR and 120DB WDR
★ Built-in Microphone, record with audio
★ Built-in microSD/SDHC/SDXC Slot, up to 256 GB
★ IP67 Dust and Waterproof Rating
★ Support PoE &DC12V
●[5MP Super HD & Color Night Vision]
* ANNKE PoE IP security camera, with OmniVision sensor and 2.8 mm professional lens, delivers 5MP Super HD footages (2592 X 1944 pixels) at 20 fps.
* The super low-light visibility tech & image sensor enables the PoE bullet camera to deliver colorful images in dim night, while other 4K/5MP cameras have turned into B&W mode.
●[Audio Recording with Built-in Mic ]
* The built-in microphone with noise reduction helps the PoE CCTV video camera to record footages with audio.
* The microphone picks up the sound to provide additional information and evidences to your security monitoring.
●[Remote Access & Accurate Motion Alerts]
* Access and control the PoE security camera system via your phones, PCs and tablets for Super HD stream and playback.
* You can customize the areas you care most to get accurate app pushes & email alerts whenever motions occurred in the marked areas.
●[Powerful H.265+ Video Format ]
* Cutting-edge H.265+ video format enables the Ethernet system to deliver faster footages without latency, and record longer videos.
* Compatible ONVIF & RTSP protocols allow the PoE IP system to work with all ONVIF devices and third-party software, like Blue Iris, Synology, etc.
●[Outdoor IP67 Weatherproof ]
* With IP67 weatherproof, the outdoor PoE surveillance camera endures any climate from torrential downpours to freezing snowstorms (-22 °F – 140 °F).
* The 2000 V lightning, surge & voltage transient protection and corrosion resistance, ensure the IP camera works perfectly in all severe weather.
●[120 dB True WDR & 3D DNR ]
* 120 dB true WDR automatically adjusts the pictures' brightness for optimized, and highly-detailed footages in all strongest light contrast conditions.
* 3D DNR filters out digital noise from dim light or any noise caused by motion for cleaner images, and reducing video file sizes.
NVR | ||
Video & Audio | Video Compression | H.265+/H.265/ H.264+/H.264 |
IP Video Input | 8CH POE | |
Video Output | HDMI & VGA Up to 1080P | |
Incoming bandwidth | 60M | |
Max Recording Resolution | Up to 6MP | |
Max Playback Resolution | Up to 6MP | |
Max Playback Channel | 8CH | |
Max Playback Capacity | 4-ch@1080P, 1-ch@6MP@25fps | |
Onvif Protocols | Support | |
Hard Drive | HDD | 1 SATA interface |
HDD Capacity | Up to 6TB capacity | |
| Network interface | RJ45x1(10/100M) |
POE | 8 Ports(IEEE802.3af/at) | |
USB | 2x USB 2.0 | |
General | Operating Power | DC48V |
Power Consumption | ≤10W(without HDD and POE) | |
POE: Max 25.5W for single port | ||
Working Temperature | 14 °F ~ 131 °F /-10 °C ~+55 °C | |
Dimensions(W x H x D) | 10.4" × 8.9" × 1.9" / 265 × 225 × 48mm | |
Weight (without hard disk) | 2.2lb / 1KG | |
IP Camera | ||
Camera | Image Sensor | 1/3" Progressive Scan CMOS |
Max resolution | 3K(3072*1728), 16: 9 picture ratio is more suitable for the most popular display | |
Main Stream | 50 Hz: 20 fps (3072*1728), 25 fps ( 1920 X 1080, 1280 X 720) | |
Substream | 50 Hz: 25 fps (1280 X 720,640 X 480, 640 X 360) | |
Video Compression | Main stream: H.265+/H.265/H.264+/H.264 | |
Video Bitrate | 32 Kbps - 6 Mbps | |
Audio Compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC | |
Audio Input | Built-in Microphone, record with audio | |
Lens | 4 mm | |
Min. Illumination | Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR | |
Angle of View | Horizontal FOV 76°, vertical FOV 41°, diagonal FOV 90° | |
Number of Infrared LEDs | 2 pcs | |
Night Vision Distance | Up to 100 ft/30 m | |
Motion detection 2.0 | Supoort, include Human & Vehicle detection | |
Image Enhancement | BLC, HLC, 3D DNR | |
Wide Dynamic Range | 120 dB WDR | |
Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, Bonjour, FTP, SMTP | |
API | Open Network Video Interface | |
Region of Interest (ROI) | 1 fixed region for main stream | |
Privacy Mask | 4 programmable polygon privacy masks | |
General Function | Mirror,rotate,password protection,video tampering alarm, remote access | |
Ethernet | 1 RJ45 10 M/100 M self-adaptive Ethernet port | |
General | Housing | Metal & Plastic |
Color | White & Black | |
Storage | Built-in microSD/SDHC/SDXC Slot, up to 256 GB | |
Hardware Reset | Yes | |
Operating Power | DC 12 V± 25%, max. 5 W; PoE (802.3af), max. 6.5 W | |
Operating Temperature | -22 °F – 140 °F/-30 °C – 60 °C | |
Indoor/Outdoor Use | Indoor/Outdoor | |
Interface Protection | IP67, TVS 2000 V Lightning Protection, Surge Protection and Voltage Transient Protection | |
Dimension (L X W X H) | 7.0" X 2.6" X 2.7"/177.6 X 66.2 X 67.8 mm | |
Weight | 0.6 lb./270 g | |
