ANNKE 5MP H.265+ Super HD PoE Network Video Security System 2.8mm Lens IP67 Outdoor POE IP Cameras Plug & Play PoE Camera Kit
IP Camera | ||
Camera | Image Sensor | 1/3" Progressive Scan CMOS |
Max resolution | 3K(3072*1728), 16: 9 picture ratio is more suitable for the most popular display | |
Main Stream | 50 Hz: 20 fps (3072*1728), 25 fps ( 1920 X 1080, 1280 X 720) | |
Substream | 50 Hz: 25 fps (1280 X 720,640 X 480, 640 X 360) | |
Video Compression | Main stream: H.265+/H.265/H.264+/H.264 | |
Video Bitrate | 32 Kbps - 6 Mbps | |
Audio Compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC | |
Audio Input | Built-in Microphone, record with audio | |
Lens | 2.8 mm | |
Min. Illumination | Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR | |
Angle of View | Horizontal FOV 99°, vertical FOV 55°, diagonal FOV 116° | |
Number of Infrared LEDs | 2 pcs | |
Night Vision Distance | Up to 100 ft/30 m | |
Motion detection 2.0 | Supoort, include Human & Vehicle detection | |
Image Enhancement | BLC, HLC, 3D DNR | |
Wide Dynamic Range | 120 dB WDR | |
Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, Bonjour, FTP, SMTP | |
API | Open Network Video Interface | |
Region of Interest (ROI) | 1 fixed region for main stream | |
Privacy Mask | 4 programmable polygon privacy masks | |
General Function | Mirror,rotate,password protection,video tampering alarm, remote access | |
Ethernet | 1 RJ45 10 M/100 M self-adaptive Ethernet port | |
General | Housing | Metal & Plastic |
Color | White & Black | |
Storage | Built-in microSD/SDHC/SDXC Slot, up to 256 GB | |
Hardware Reset | Yes | |
Operating Power | DC 12 V± 25%, max. 5 W; PoE (802.3af), max. 6.5 W | |
Operating Temperature | -22 °F – 140 °F/-30 °C – 60 °C | |
Indoor/Outdoor Use | Indoor/Outdoor | |
Interface Protection | IP67, TVS 2000 V Lightning Protection, Surge Protection and Voltage Transient Protection | |
Dimension (L X W X H) | 7.0" X 2.6" X 2.7"/177.6 X 66.2 X 67.8 mm | |
Weight | 0.6 lb./270 g | |
IP Camera | ||
Camera | Image Sensor | 1/3" Progressive Scan CMOS |
Max resolution | 3K(3072*1728), 16: 9 picture ratio is more suitable for the most popular display | |
Main Stream | 50 Hz: 20 fps (3072*1728), 25 fps ( 1920 X 1080, 1280 X 720) | |
Substream | 50 Hz: 25 fps (1280 X 720,640 X 480, 640 X 360) | |
Video Compression | Main stream: H.265+/H.265/H.264+/H.264 | |
Video Bitrate | 32 Kbps - 6 Mbps | |
Audio Compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC | |
Audio Input | Built-in Microphone, record with audio | |
Lens | 2.8 mm | |
Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR | |
Angle of View | Horizontal FOV 98°, vertical FOV 54°, diagonal FOV 114° | |
Supplement Light Type | Smart Dual-Light, IR, White Light | |
Supplement Light Range | Up to 30 m | |
Motion detection 2.0 | Supoort, include Human & Vehicle detection | |
Image Enhancement | BLC, HLC, 3D DNR | |
Wide Dynamic Range | 120 dB WDR | |
Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP | |
API | Open Network Video Interface Version 18.12 | |
Region of Interest (ROI) | 1 fixed region for main stream | |
Privacy Mask | 4 programmable polygon privacy masks | |
General Function | Mirror,rotate,password protection, remote access | |
Ethernet | 1 RJ45 10 M/100 M self-adaptive Ethernet port | |
General | Housing | Metal & Plastic |
Color | White & Black | |
Storage | Built-in microSD/SDHC/SDXC Slot, up to 512 GB | |
Hardware Reset | Yes | |
Operating Power | DC 12 V± 25%, max. 5 W; PoE (802.3af), max. 6.5 W | |
Operating Temperature | -22 °F – 140 °F/-30 °C – 60 °C | |
Indoor/Outdoor Use | Indoor/Outdoor | |
Interface Protection | IP67 | |
Dimension (L X W X H) | 170.8 mm × 66 mm × 69.1 mm (6.7" × 2.6" × 2.7") | |
Weight | 0.6 lb./270 g | |
The outdoor PoE security camera, with professional 5MP OmniVision sensor and 2.8 mm lens, delivers sharpest Super HD images and 100 ft EXIR 2.0 night vision (2592 X 1944 pixels) at 20 fps.Color Night Vision in Super Low-Light Conditions
The advanced super low-light visibility tech enables the Ethernet security camera to provide color images in extreme darkness, while other 4K/5MP cameras have turned into B&W mode.120 dB True WDR & 3D DNR
120 dB true WDR automatically adjusts the image brightness for crystal images in strongest light contrast conditions. 3D DNR helps to produce sharp footages without noise.Audio Recording with Built-in Mic
With the built-in microphone, the smart PoE video camera records crisp videos with audio. Watch and hear to know what happened around your home.Remote Access & Motion Alerts
Access the PoE bullet IP camera remotely via your phones, PCs, tablets and browsers anywhere. Get instant app pushes & email alerts with snapshots when there are motion events.Advanced H.265+ Stream & ONVIF Compatibility
The whole CCTV IP system supports H.265+ coding, providing fast stream without latency & saving storage space. ONVIF & RTSP protocols help the system work with all ONVIF devices & third-party software, like Blue Iris, Synology, etc.
Easy Plug & Play PoE Installation
Plug the PoE camera to the NVR with just a network cable for both data and power transmission. Even a beginner can install the system within minutes.Outdoor IP67 Weatherproof
The outdoor PoE security camera, with durable IP67 weatherproof housing, stands firmly from torrential downpours to freezing snowstorms (-22 °F to 140 °F).
8CH+4PCS NVT Kit Package Include:
8CH+8PCS NVT Kit Package Include:
