ANNKE 12MP Smart Dual Light Camera Kits Security Cam 8CH NVR 8PCS POE Camera Outdoor CCTV Video Surveillance Protection Camera
★ 12MP smart dual light turret network camera
★ 2.8mm lens brings everything back to life
★ Efficient H.265+ compression technology
★ Motion detection 2.0 with human & Vehicle Detection
★ Clear day and night vision with 3D DNR and 120 DB WDR
★ Built-in microphone for real-time audio security
★ Support on-board storage up to 512 GB (SD card slot)
★ IP67 Dust and Waterproof Rating
★ Support PoE &DC12V
· Live view, recording&playback up to 12 MP resolution
· Up to 8 channel IP cameras can be connected with built-in PoE inputs
· Advanced H.265+ Video Compression
· Supports iPhone, iPad, Android mobile remote monitoring
· Connectable to the third-party network cameras
· HDMI Video output at up to 4K (40960 × 2160) resolution
· Annke Vision for easy remote view
· Support 4-ch Human and vehicle targets detection
NVR | ||
Video & Audio | Decoding Format | H.264+/H.264/H.265/H.265+ |
IP Video Input | 8CH PoE | |
Video Output | HDMI up to 4K (4096 × 2160), VGA up to 1080p(1920 × 1080) | |
Audio Input/Output | 1/1 RCA | |
Incoming/outgoing Bandwidth | 80/80 Mbps | |
Max Recording Resolution | Up to 12MP(4096 X 3072)@30fps(Frame rate depends on IP camera) | |
Max Playback Resolution | Up to 12MP(4096 X 3072)@30fps(Frame rate depends on IP camera) | |
Max Playback Channel | 8CH | |
Max Playback Capacity | 1-ch@12 MP(4096 X 3072) (30 fps)/3-ch@4 MP (30 fps)/6-ch@1080p (30 fps) | |
Hard Drive | HDD | 1 SATA Interface |
HDD Capacity | Up to 8 TB Capacity | |
External Interface | Network Interface | 1, RJ-45 10/100Mbps self-adaptive Ethernet interface |
PoE | 8, RJ-45 10/100 Mbps self-adaptive Ethernet interface, IEEE 802.3 af/at | |
USB interface | USB 2.0*2 | |
Smart Function | Deep learning | 8-ch Human and vehicle targets detection(Need IP camera support) |
4-ch Human and vehicle targets detection(IP camera does not need to support this function but the resolution cannot exceed 4MP) | ||
Smart Event | Line crossing detection, intrusion detection, region entrance detection, region exiting | |
General | Operating Power | DC 48 V |
Power Consumption | ≤10 W (Without HDD and PoE) | |
PoE: Max 25.5 W for Single Port | ||
Working Temperature | 14 °F ~ 131 °F/-10 °C ~+55 °C | |
Dimensions (W X H X D) | 12.4' X 9.4' X 1.9'/315 X 240 X 48 mm | |
Weight (Without Hard Disk) | 2.2 lbs/1 kg | |
